New
Blue-sea
Mini Dual Circuit Switch
MFR #6010
Τιμή: 58,67€ + ΦΠΑ
Online τιμή: 56,32€ + ΦΠΑ
Διαθεσιμο κατοπιν παραγγελιας
Mini Dual Circuit Switch
Simultaneously switches two isolated battery banks.
| Specifications | |
|---|---|
| Switch Type | Dual Circuit |
| Color | Red |
| Switch Positions | 2 |
| Battery Combine | No |
| Alternator Field Disconnect | No |
| Maximum Voltage | 32V DC |
| Stud Size | 3/8" |
| Terminal Stud Torque | 120 in-lb (13.56 Nm) |
| Continuous Rating | 300A |
| Intermittent Rating | 450A (5 min) |
| Cranking Rating 30 sec | 675A per circuit |
| Battery Inputs | 2 |
| Cable Clearance For 4/0 AWG Cables | 1.12in (28.45 mm) |
| Cable Size to Meet Ratings | 4/0 AWG (120mm²) |
| Mounting Holes | Accept #10 Screw |
| Stud Material | Tinned Copper |
| Stud Torque | 120 in-lb (13.56 Nm) |
| Terminal Stud Size | 3/8" - 16 (M10) |
| Weight | 0.80lb (0.36 kg) |
| Weight | 0.80lb (0.36 kg) |
Mini Dual Circuit Switch
-
Status
New
Accessory TypeBattery Switch
-
Description
Mini Dual Circuit Battery Switch
Suitable for2x batteries LiFePO4, Li-ion or Lead Acid batteries
Boats, Cars, RVsColorRed
-
Extras
Max: 32VDC 300A
Cable size 4/0 AWG 120mm²
Accept #10 Screw
Material: Tinned Copper
3/8" - 16 (M10) Stud size
2 Positions.Warranty3-Years
Country of OriginUSA
-
Total Weight (KG)
0.36
Total Dimensions (WxHxD) (mm)32x32x18
AvailabilityUsually in 5working days
